| Parameter | Specification |
|---|---|
| Width | 13 ft 5 in (4120 mm) |
| Length | 15 ft 8 in (4800 mm) |
| Height | 12 ft 1 in (3700 mm) |
| Weight | 5,500 lb (2500 kg) |
| Footprint with Bales | 4820 mm x 4120 mm (L x W) |
| Electrical Power | L16-20R + 3-Pole / 4-Wire
|
| Data Network | 1 x 10-100-1000 Quad Output
|
| Air Supply | Dry air pressure 90-95 psi (6-10 bar) and
|
| Temp Work Operation | 41°F to 104°F (5°C to 40°C) |
| Tech Spec | OS: PackNet Server v3.2 or newer
|
| Cycle Time Dependent | Dependent upon box design complexity, the size of the packaging as well as the configuration and number of tool heads.
|
| Capacity Efficiency | 10 个到几百个 / 分钟（根据箱体尺寸和设备配置） |
